Chain Link Fence
Chain Link Fence
Galvanized chain link for residential, commercial, and industrial security
- Material
- Galvanized Steel Wire
- Mesh Size
- 25mm - 100mm (1" - 4")
- Wire Gauge
- 1.6mm - 5.0mm (BWG 6-16)
- Height
- 1.0m - 4.0m
- Finish
- Galvanized / PVC Coated
Product Description
WANSUN Chain Link Fence is woven from galvanized steel wire in a diamond pattern, providing a durable, see-through barrier for residential, commercial, industrial, and recreational applications. The interlocked diamond weave provides excellent security while maintaining visibility. Available in galvanized and PVC-coated finishes with various wire gauges and mesh sizes.
Full Specifications
| Material | Q195 low carbon steel wire, galvanized |
|---|---|
| Mesh Opening | 25mm (1"), 40mm (1.6"), 50mm (2"), 60mm, 75mm (3"), 100mm (4") |
| Wire Diameter | 1.6mm to 5.0mm (BWG 16-6) |
| Fence Height | 1.0m, 1.2m, 1.5m, 1.8m, 2.0m, 2.4m, 3.0m, 4.0m |
| Roll Length | 5m, 10m, 15m, 25m, 50m |
| Galvanizing | EG (8-15 microns) / HDG (40-70 microns, 240-480g/sqm) |
| PVC Coating | Green (RAL 6005), Black, or custom; 0.2-0.8mm thickness |
| Knuckle Type | Both ends knuckled (standard) / One end twisted |
| Selvedge | Knuckle-knuckle (K-K), Twist-knuckle (T-K) |
| Tensile Strength | 500-900 MPa |
| Zinc Coating Class | Class 1 (120g/sqm), Class 3 (230g/sqm), Class A (480g/sqm) |
| Standards | ASTM A392, EN 10223-3, ISO 7990 |
Key Features
See-Through Security
Diamond weave provides security barrier while maintaining visibility for surveillance.
Multi-Finish Options
Galvanized for durability, PVC coated for aesthetics and extra corrosion protection.
Flexible Installation
Available in rolls for terrain-conforming installation or panels for modular fencing.
Self-Supporting
Interlocked diamond weave holds its shape, requiring only tension bars at posts.
Applications
Residential Security
Commercial Perimeter
Sports Courts
Industrial Sites
Frequently Asked Questions
What wire gauge is recommended for residential chain link fence?
For residential applications, 2.5mm (11 BWG) galvanized wire with 50mm (2") mesh is standard. For commercial and high-security applications, 3.0-4.0mm (10-8 BWG) with 25-40mm mesh provides enhanced security. For sports courts, 3.5-4.0mm with 45mm mesh is typical.
Should I choose galvanized or PVC-coated chain link?
Galvanized chain link is more economical and sufficient for most applications. PVC-coated chain link provides better aesthetics (green blends with landscape), additional corrosion protection, and longer life in coastal areas. PVC coating adds approximately 30-40% to the cost.
What mesh size should I use for tennis court fencing?
For tennis courts, 45mm x 45mm mesh with 3.5mm wire is the standard. This prevents balls from passing through while maintaining good visibility. For multi-sport courts, 50mm mesh is also acceptable. Court fencing height is typically 3.0-4.0m.
Can chain link fence be installed on uneven terrain?
Yes, chain link fence conforms well to slopes and uneven terrain. For gradual slopes, standard roll installation works. For steep slopes, the fence can be stepped at each post. We can also pre-cut panels to match specific terrain profiles.
